Multifunction Sensor

Where to Buy Design Studio
Sensors
arrow right
Multifunction Sensor
Overview
Features
Downloads
Where to Buy Design Studio

DUS360CS-D

Multifunction Sensor

360° ceiling surface mounted sensor powered by the DALI network

The Philips Dynalite DUS360CS-D is a surface mountable 360 degree multifunction sensor that combines motion detection (PIR), infrared remote control reception (IR) and ambient light level detection (PE) into one device in applications such as hotels, restaurants and homes.

Read More

Key Features

DALI device

Designed to operate seamlessly with the Philips Dynalite DDBC120-DALI or DDBC320-DALI controller.

Powered directly by the DALI network

Eliminates the need for additional network field wiring.

Motion detection feature

Detects the presence or absence of motion and adjusts lights accordingly.

Segmented click-up bezel

Surrounds the motion sensor element and enables a portion of the sensing field to be masked. This prevents nuisance detection from adjacent doorways or corridors.

Multiple mounting options

Can be partially recessed or surface-mounted using the supplied butterfly clips or junction box.

Daylight harvesting mode

Delivers automatic energy savings and maintains the illuminance of a space throughout the day.

Infrared receive capability

Manually adjust light levels using a hand-held remote control, via the inbuilt IR receiver.

Corridor hold

Links corridor areas with adjacent rooms so corridor remains lit while occupancy is detected in adjacent rooms.

Product Guides & Documentation

Networked Sensor Brochure Networked Sensor Brochure
Networked Sensor Brochure
DUS360CS-D Installation Instructions DUS360CS-D Installation Instructions
DUS360CS-D Installation Instructions
CE
DUS360CS-D EU Declaration of Conformity
UKCA
DUS360CS UKCA Declaration of Conformity
UL
DUS360 UL Certificate of Compliance
CAD
DUS360CS-DALI AutoCAD Drawing
Certs
UI and Sensor Service Guide
Certs
DUS360CS-D Spec Sheet
